Traxxas TRX-4 1972 Chevrolet K5 Blazer High Trail Edition 1:10 4WD RTR – Red

Traxxas High Trail Edition™ TRX-4® models are the biggest and baddest trucks on the trail and now classic Blazer fans have reason to celebrate. The 1972 Chevrolet® K5 Blazer gets the full High Trail treatment with a big, lifted stance and beautifully detailed body. The factory-installed Long Arm Lift Kit boosts the Blazer’s ground clearance by more than an inch with larger 2.2″ wheels and tires to conquer the roughest terrain. K5 Blazer High Trail Edition delivers more of what you crave—extreme all-terrain capability, stunning scale looks, and Traxxas-Tough™ durability

HIGH TRAIL EDITION
Large 2.2″ chrome mag wheels and Canyon Trail tires tame even the most technical trails to extend your scale adventures farther than ever before. The factory-installed Long Arm Lift Kit raises K5 Blazer over an inch taller for superior ground clearance.

DETAILED REPLICA BODY
The TRX-4 K5 Blazer faithfully reproduces one of the most iconic Chevy trucks to ever hit the trail. Bright chrome accents contrast the high-gloss paint for an unmistakable look. The injection-molded grille, side mirrors, and simulated wood trim give K5 Blazer uncompromising scale presence.

CLIPLESS BODY MOUNTING
The clipless body’s hidden latching system gives K5 Blazer High Trail Edition clean, flowing lines for new level of scale realism and convenience. On the trail, K5 Blazer’s clipless body holds tight when you need it, but releases in just seconds to access the chassis.

Features:

• Officially Licensed 1972 Chevrolet® K5 Blazer Body
• Clipless Body Mounting
• Trail-tuned XL-5 HV Waterproof Electronic
• Powerful Titan® 21T reverse rotation motor with internal cooling fan
• Factory-Installed Long Arm Lift Kit
• Steel Ladder Frame: 312 mm wheelbase
• Portal Axles
• Innovative Battery Compartment
• Two speed high/low range with remote shifting
• Chassis mounted 2075X metal gear digital servo
• Extended Aluminum GTS Shocks
• Oversize Wheels and Tires
• TQi™ 2.4GHz 4-channel transmitter
• Sealed Ball Bearings
• Hex hardware with rust-resistant black oxide coating

Specs

• Length: 20.67 inches (525mm)
• Front Track: 10.63 inches (270mm)
• Rear Track: 10.63 inches (270mm)
• Center Ground Clearance: 4 inches (99mm)
• Weight (w/o battery): 7.26lbs (3.30kg)
• Height (overall): 11.22 inches (285mm)
• Wheelbase: 12.28 inches (312mm)
• Approach Angle: 69.2°
• Departure Angle: 55.7°
• Breakover Angle: 79.3°
• Front Shock Length: 4.33 inches (110mm)
• Rear Shock Length: 4.33 inches (110mm)
• Front Wheels: 2.2 x 1.34 inches (56 x 34mm)
• Rear Wheels: 2.2 x 1.34 inches (56 x 34mm)
• Front Tires: 5.3 x 2.14 inches (135 x 54mm)
• Rear Tires: 5.3 x 2.14 inches (135 x 54mm)
• Hex Size: 12mm
• Speed Control: XL-5 HV
• Motor (electric): 21T Reverse Rotation
• Transmission: 2-speed High/Low, Remote Shifting
• Gear Pitch: 32P
• Differential Type: 4 Gear, Remote Locking
• Chassis Structure / Material: Steel Ladder Frame with Nylon Composite Crossmembers
• Brake Type: Electronic “Hill Hold”
• Drive System: Shaft Driven 4WD
• Steering: Chassis Mounted Servo
• Servo: 2075X Metal Gear
• Transmitter: TQi™ 2.4 GHz 4-Channel Transmitter
• Receiver: 6533
• Skill Level: 1
• Battery Tray: 158.75 L x 47 W x 23/26mm H

What’s In The Box:

• TRX-4, Ready-To-Race® model
• XL-5 HV waterproof electronic speed control
• Titan® 21T reverse rotation motor
• TQi™ 2.4GHz radio system with cruise control
• High quality maintenance tools

What You’ll Need:
Batteries

• TRX-4 accepts a wide variety of NiMH (4–7 cell) and LiPo (2s–3s) batteries.

Charger

• Traxxas EZ-Peak® Live charger is recommended for easy and fast charging performance (model #2971).

AA Alkaline Batteries

• Four AA alkaline batteries for the transmitter.
• Specification

  Manufacturer	Traxxas
  Part Number	TRX92086-4-RED
  EAN	020334920867
  Motor Type	Brushed
  Waterproofing	Waterproof
  Drive	4WD
  Surface Type	Off-Road
  Assembly Type	Assembled (RTR)
  Scale	1:10
  Vehicle	Rock Crawler
  Skill Level	Skill Level 1 What’s this?
  Power Bundles	Power Bundle Required
